S-FAB™ PDM 17-24

S-FAB™ PDM 17-24 Semi-Automatic Pivot Type Double Miter Bandsaw with Standard Options

  • 17″ x 24″ Flat Capacity
  • Ø17″ Round Capacity

Description

The Revolution Machine Tools™ S-FAB™ PDM 17-24 Semi-Automatic Pivot Type Double Miter Bandsaws are ideal for urgent cutting of materials with variable number of cuts. It is the largest model in its class as articulated with 17” x 24” blade cutting size and Ø17” cutting size in 90° cuts. It is possible to make angled cuts between +60° RIGHT -60° LEFT by angling the upper body of our machines. Our machines make the cutting hydraulically and automatically rise to the cutting height after the cutting is finished. The material is manually driven up to the stop and the cut is repeated.



The S-FAB™ PDM 17-24 Bandsaw comes standard equipped with a control panel, blade brush, hydraulic vise, security switch, Siti heavy duty gearbox, infinite variable speed inverter, sensitive pressure control, hydromechanical blade tension, optical saw height adjustment, linear guide rails, coolant pump, 230V or 440V 3 phase power.



Buyers have the option to add any of these additional features to their S-FAB™ PDM 17-24 Bandsaw as well: Hydraulic blade tension, hydraulic top clamping, DropsA air/oil clean lubrication system, micromist cooling, 10ft roller table with the option to make the table motorized, laser line, and single phase – 220V 1 phase power.

RMT-REVOLUTION-MACHINE-TOOLS-S-FAB-PDM-17-24 (1)
